New-Energy Vehicle Inspection
A coordinated display, control, and measurement architecture for electric-vehicle inspection lines.
The cross-station coordination challenge
Electric-vehicle inspection coordinates operator displays, powered actuators such as motors and cylinders, warning devices, and multiple digital and analog measurement signals across stations. Any inconsistency between station states directly affects the continuity and safety of the inspection sequence.
A three-layer system architecture
Cartesy organizes the line into display, control, and measurement layers: the display layer presents station status and test results, the control layer schedules actuators and warning devices, and the measurement layer acquires digital and analog signals.
- Display layer: unified presentation of station status and test results
- Control layer: scheduling of motors, cylinders, and warning devices
- Measurement layer: acquisition and measurement of digital and analog signals
Coordinated operation
The three layers operate as one system: station status, test results, actuators, and collected signals interlock, so electric-vehicle inspection completes continuously and in order according to the defined sequence.
